| Spindle Pitch, |
181 mm |
| Machine Width |
3 Feet |
| Machine Height |
6'-5" Feet |
| Spindle in Section |
28 nos |
| Spindle Pot |
70 mm dia mm dia Hard Anodies & Plazma Cotting & S.S. |
| Feed Tensioner |
Boll Ceramic |
| Over Feed |
Excellent Self Design Suitable for cone winding |
| Take up Traversing |
Common suitable for cylindrical or Bioconical Gear Box |
| Denior |
30 to 150 Denior Twist |
| Viable Twist Range |
250 TPM to 3500TPM |
| Spindle RPM |
Up to 16000 (MECHANICAL SPEED) |
| Feed Bobbin |
32 x 36 x 240/270 mm Alluminium / plastic Tubes up to 95 Dia |
| Yarn Take up speed |
Up to 60 Met/ Min |
| Take up Package |
On spring pressure Hinge Creadle |
| Cheese & Roll |
Cheese 57X 69X155 & Roll 135f X85 drum X157 Total Length |
| Caintain |
Cheese 1.500 KG & Roll 900 gm |
| Display |
RPM / TPM /Met/Min |
